Tables
Tables are built structurally rather than by column count. doc.AddTable()
returns an empty table, AddRow() appends a row, and AddCell() appends a cell
to that row. Nothing fixes the number of columns in advance, so a table is only
as regular as the rows you add to it.
table := doc.AddTable()
table.Properties().SetWidthPercent(100)
row := table.AddRow()
row.AddCell().AddParagraph().AddRun().AddText("Name")
row.AddCell().AddParagraph().AddRun().AddText("Value")A cell holds paragraphs, not text. AddCell() gives you a cell and you still
need AddParagraph() and AddRun() before any characters appear, which is why
the snippet chains four calls to write one string. The same is true in reverse:
a cell can hold several paragraphs, a nested table, or a structured document
tag, and Word will not open a file whose cell does not end with a paragraph.
Where the settings live
Four Properties() calls return four different types, and picking the wrong
level is the usual reason a setting appears to do nothing.
| Level | Type | Covers |
|---|---|---|
table.Properties() | TableProperties | Width, alignment on the page, layout, table borders, style name, table look. |
row.Properties() | RowProperties | Height, splitting across pages, repeating as a header row. |
cell.Properties() | CellProperties | Cell width, shading, column span, vertical merge, vertical alignment, cell borders and margins. |
paragraph.Properties() | ParagraphProperties | Horizontal alignment of the text, spacing, keep-with-next. |
Width comes in an absolute form and a percentage form on both tables and cells:
SetWidth takes a measurement.Distance and SetWidthPercent takes a number
from 0 to 100. They are alternatives rather than a pair. Both write the same
underlying width element, so setting one after the other keeps only the value
set last, with no error and no combination of the two. SetWidthAuto() is the
third option and hands sizing back to the layout engine.
Cell widths are preferences, not commands. Under the default autofit layout Word
may override them to fit the content;
table.Properties().SetLayout(wml.ST_TblLayoutTypeFixed) is what makes them
binding.
Horizontal and vertical merging use different mechanisms. A cell spanning
columns is one cell with SetColumnSpan(n), while a vertical merge is declared
per row, with wml.ST_MergeRestart on the top cell and wml.ST_MergeContinue
on each cell below it. Only the restart cell’s text is rendered.
Where to look
| Guide | Covers |
|---|---|
| Create and Format a Table | Rows and cells, widths, borders, shading, column and vertical spans, row height, and table styles with banding. |
| Paragraphs in Cells | Several paragraphs in one cell, positioning them relative to each other, and nesting tables. |
| Keep a Row on One Page | Stopping a row from splitting across a page break, and the related keep-with-next setting. |
